KFbxTrimNurbsSurface Class Reference
#include
<kfbxtrimnurbssurface.h>
Detailed Description
KFbxTrimNurbsSurface Describes a nurbs surface with regions trimmed or cut away with trimming boundaries.Definition at line 158 of file kfbxtrimnurbssurface.h.
Public Member Functions |
|
| virtual EAttributeType | GetAttributeType () const |
| Return the type of node attribute. |
|
| int | GetTrimRegionCount () const |
| Returns the number of regions on this
trimmed nurbs surface. |
|
| void | BeginTrimRegion () |
| Call this before adding boundaries for a new
trim region. |
|
| void | EndTrimRegion () |
| Call this after the last boundary for a
given region is added. |
|
| bool | AddBoundary (KFbxBoundary *pBoundary) |
| Appends a trimming boundary to the set of
trimming boundaries. |
|
| KFbxBoundary * | GetBoundary (int pIndex, int pRegionIndex=0) |
| Gets the boundary at a given index for a
given region. |
|
| KFbxBoundary const * | GetBoundary (int pIndex, int pRegionIndex=0) const |
| Gets the boundary at a given index for a
given region. |
|
| int | GetBoundaryCount (int pRegionIndex=0) const |
| Gets the number of boundaries on this
surface. |
|
| void | SetNurbsSurface (KFbxNurbsSurface const *pNurbs) |
| Set the nurbs surface that will be trimmed
by the trimming boundaries. |
|
| KFbxNurbsSurface * | GetNurbsSurface () |
| Gets the untrimmed surface that is trimmed
by the trim boundaries. |
|
| KFbxNurbsSurface const * | GetNurbsSurface () const |
| Gets the untrimmed surface that is trimmed
by the trim boundaries. |
|
| void | SetFlipNormals (bool pFlip) |
| The normals of the surface can be reversed
to reverse the surface. |
|
| bool | GetFlipNormals () const |
| Check if the normals are flipped. |
|
| virtual int | GetControlPointsCount () const |
| Return the nurb surface's control points
count. |
|
| virtual void | SetControlPointAt (KFbxVector4 &pCtrlPoint, KFbxVector4 &pNormal, int pIndex) |
| Set a control point of the nurb surface.
|
|
| virtual KFbxVector4 * | GetControlPoints () const |
| Return the nurb surface's control points.
|
|
|
Shape Management
|
|
| virtual int | AddShape (KFbxShape *pShape, char const *pShapeName) |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
| virtual void | ClearShape () |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
| virtual int | GetShapeCount () const |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
| virtual KFbxShape * | GetShape (int pIndex) |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
| virtual KFbxShape const * | GetShape (int pIndex) const |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
| virtual char const * | GetShapeName (int pIndex) const |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
| virtual KFCurve * | GetShapeChannel (int pIndex, bool pCreateAsNeeded=false, char const *pTakeName=NULL) |
| Shapes on trim nurbs are stored on the
untrimmed surface. |
|
Member Function Documentation
| virtual EAttributeType GetAttributeType | ( | ) | const [inline, virtual] |
Return the type of node attribute.
Reimplemented from KFbxGeometry.
Definition at line 163 of file kfbxtrimnurbssurface.h.
| int GetTrimRegionCount | ( | ) | const |
Returns the number of regions on this trimmed nurbs surface.
Note there is at always at least one trim region.
- Returns:
- The number of regions
| void BeginTrimRegion | ( | ) |
Call this before adding boundaries for a new trim region.
The number of regions is incremented on this call.
| void EndTrimRegion | ( | ) |
Call this after the last boundary for a given region is added.
If no boundaries are added in between calls to BeginTrimRegion and EndTrimRegion, the last region is removed.
| bool AddBoundary | ( | KFbxBoundary * | pBoundary | ) |
Appends a trimming boundary to the set of trimming boundaries.
The first boundary specified for a given trim region should be the outer boundary. All other boundaries are inner boundaries. This must be called after a call to BeginTrimRegion(). Boundaries cannot be shared among regions. Duplicate the boundary if necessary. See KFbxBoundary
- Parameters:
-
pBoundary The boundary to add.
- Returns:
- true if the boundary was added, false otherwise
| KFbxBoundary* GetBoundary | ( | int | pIndex, | |
| int | pRegionIndex = 0 |
|||
| ) |
Gets the boundary at a given index for a given region.
- Parameters:
-
pIndex The index of the boundary to retrieve. No bounds checking is done. pRegionIndex The index of the region which is bound by the boundary.
- Returns:
- The trimming boundary at index pIndex, if pIndex is in the range [0, GetBoundaryCount() ) otherwise the result is undefined.
| KFbxBoundary const* GetBoundary | ( | int | pIndex, | |
| int | pRegionIndex = 0 |
|||
| ) | const |
Gets the boundary at a given index for a given region.
- Parameters:
-
pIndex The index of the boundary to retrieve. No bounds checking is done. pRegionIndex The index of the region which is bound by the boundary.
- Returns:
- The trimming boundary at index pIndex, if pIndex is in the range [0, GetBoundaryCount() ) otherwise the result is undefined.
| int GetBoundaryCount | ( | int | pRegionIndex = 0 |
) | const |
Gets the number of boundaries on this surface.
- Parameters:
-
pRegionIndex The index of the region
- Returns:
- The number of trim boundaries
| void SetNurbsSurface | ( | KFbxNurbsSurface const * | pNurbs | ) |
Set the nurbs surface that will be trimmed by the trimming boundaries.
- Parameters:
-
pNurbs Nurbs
| KFbxNurbsSurface* GetNurbsSurface | ( | ) |
Gets the untrimmed surface that is trimmed by the trim boundaries.
- Returns:
- Pointer to the (untrimmed) nurbs surface.
| KFbxNurbsSurface const* GetNurbsSurface | ( | ) | const |
Gets the untrimmed surface that is trimmed by the trim boundaries.
- Returns:
- Pointer to the (untrimmed) nurbs surface.
| void SetFlipNormals | ( | bool | pFlip | ) | [inline] |
The normals of the surface can be reversed to reverse the surface.
- Parameters:
-
pFlip If true, the surface is reversed, else the surface is not reversed.
Definition at line 237 of file kfbxtrimnurbssurface.h.
| bool GetFlipNormals | ( | ) | const [inline] |
Check if the normals are flipped.
- Returns:
- True if normals are flipped, false otherwise
Definition at line 242 of file kfbxtrimnurbssurface.h.
| virtual int AddShape | ( | KFbxShape * | pShape, | |
| char const * | pShapeName | |||
| ) | [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->AddShape() See KFbxGeometry::AddShape() for method description.
- Parameters:
-
pShape Pointer to the shape object. pShapeName Name given to the shape.
- Returns:
- -1
Reimplemented from KFbxGeometry.
| virtual void ClearShape | ( | ) | [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->ClearShape() See KFbxGeometry::ClearShape() for method description.
Reimplemented from KFbxGeometry.
| virtual int GetShapeCount | ( | ) | const [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->GetShapeCount() See KFbxGeometry::GetShapeCount() for method description.
Reimplemented from KFbxGeometry.
| virtual KFbxShape* GetShape | ( | int | pIndex | ) | [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->GetShape() See KFbxGeometry::GetShape() for method description.
- Parameters:
-
pIndex Index of shape.
Reimplemented from KFbxGeometry.
| virtual KFbxShape const* GetShape | ( | int | pIndex | ) | const [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->GetShape() See KFbxGeometry::GetShape() for method description.
- Parameters:
-
pIndex Index of shape.
Reimplemented from KFbxGeometry.
| virtual char const* GetShapeName | ( | int | pIndex | ) | const [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->GetShapeName() See KFbxGeometry::GetShapeName() for method description.
- Parameters:
-
pIndex Index of shape.
Reimplemented from KFbxGeometry.
| virtual KFCurve* GetShapeChannel | ( | int | pIndex, | |
| bool | pCreateAsNeeded =
false, |
|||
| char const * | pTakeName = NULL |
|||
| ) | [virtual] |
Shapes on trim nurbs are stored on the untrimmed surface.
Thus, this is equivalent to calling GetNurbsSurface()->GetShapeChannel() See KFbxGeometry::GetShapeChannel() for method description.
- Parameters:
-
pIndex Shape index. pCreateAsNeeded If true, the fcurve is created if not already present. pTakeName Take from which we want the FCurve (if NULL, use the current take).
Reimplemented from KFbxGeometry.
| virtual int GetControlPointsCount | ( | ) | const [virtual] |
Return the nurb surface's control points count.
Reimplemented from KFbxGeometryBase.
| virtual void SetControlPointAt | ( | KFbxVector4 & | pCtrlPoint, | |
| KFbxVector4 & | pNormal, | |||
| int | pIndex | |||
| ) | [virtual] |
Set a control point of the nurb surface.
- Parameters:
-
pCtrlPoint The control point's location. pNormal The control point's normal. pIndex The index of control point to be set.
| virtual KFbxVector4* GetControlPoints | ( | ) | const [virtual] |
Return the nurb surface's control points.
Reimplemented from KFbxGeometryBase.
