KFbxLodGroup Class Reference
#include
<kfbxlodgroup.h>
Detailed Description
This node attribute contains the properties of a null node.Definition at line 54 of file kfbxlodgroup.h.
Public Types |
|
| enum | EDisplayLevel |
| types. More... |
|
Public Member Functions |
|
| virtual EAttributeType | GetAttributeType () const |
| Return the type of node attribute which is
EAttributeType::eLODGROUP. |
|
| int | GetNumThresholds () const |
| Get the size of the threshold list. |
|
| bool | AddThreshold (fbxDistance pThreshValue) |
| Add a new threshold value to the current
list. |
|
| bool | SetThreshold (int pEl, fbxDistance pThreshValue) |
| Set the threshold value for the specified
object. |
|
| bool | GetThreshold (int pEl, fbxDistance &pThreshValue) |
| Get the threshold value for the specified
object. |
|
| int | GetNumDisplayLevels () const |
| Get the size of the displayLevel list.
|
|
| bool | AddDisplayLevel (KFbxLodGroup::EDisplayLevel pValue) |
| Add a new displayLevel value to the current
list. |
|
| bool | SetDisplayLevel (int pEl, KFbxLodGroup::EDisplayLevel pValue) |
| Set the display level value for the
specified object. |
|
| bool | GetDisplayLevel (int pEl, KFbxLodGroup::EDisplayLevel &pValue) |
| Get the display level value for the
specified object. |
|
Public Attributes |
|
| KFbxTypedProperty< fbxBool1 > | MinMaxDistance |
| This property handles the use of the Min/Max
distances. |
|
| KFbxTypedProperty< fbxDouble1 > | MinDistance |
| This property handles the Min distance
value. |
|
| KFbxTypedProperty< fbxDouble1 > | MaxDistance |
| This property handles the Max distance
value. |
|
| KFbxTypedProperty< fbxBool1 > | WorldSpace |
| This property handles the WorldSpace flag.
|
|
Member Enumeration Documentation
| enum EDisplayLevel |
Member Function Documentation
| virtual EAttributeType GetAttributeType | ( | ) | const [virtual] |
Return the type of node attribute which is EAttributeType::eLODGROUP.
Reimplemented from KFbxNodeAttribute.
| int GetNumThresholds | ( | ) | const |
Get the size of the threshold list.
- Returns:
- The current size of the threshold list.
| bool AddThreshold | ( | fbxDistance | pThreshValue | ) |
Add a new threshold value to the current list.
- Parameters:
-
pThreshValue Threshold distance from the previous entry in the threshold list
- Remarks:
- This list can only expand so the only way to shrink it, is to
completely destroy this object.
This method does not check the received values and blindly add them to the list. Therefore duplicated values can exist in different positions in the list.
- Returns:
- true if successful and false if any error occurred.
| bool SetThreshold | ( | int | pEl, | |
| fbxDistance | pThreshValue | |||
| ) |
Set the threshold value for the specified object.
- Parameters:
-
pEl The index of the object we want to set the threshold. pThreshValue Threshold distance from the previous entry in the threshold list
- Returns:
- true if successful and false if the specified index is invalid.
| bool GetThreshold | ( | int | pEl, | |
| fbxDistance & | pThreshValue | |||
| ) |
Get the threshold value for the specified object.
- Parameters:
-
pEl The index of the object we want to get the threshold. pThreshValue the current threshold value.
- Returns:
- true if successfull and false if the specified index is invalid.
- Remarks:
- in case of a failure, the pThreshValue is left unchanged.
| int GetNumDisplayLevels | ( | ) | const |
Get the size of the displayLevel list.
- Returns:
- The current size of the displayLevel list.
| bool AddDisplayLevel | ( | KFbxLodGroup::EDisplayLevel | pValue | ) |
Add a new displayLevel value to the current list.
- Parameters:
-
pValue Display level value
- Remarks:
- This list can only expand so the only way to shrink it, is to
completely destroy this object.
This method does not check the received values and blindly add them to the list. Therefore duplicated values can exist in different positions in the list.
- Returns:
- true if successful and false if any error occurred.
| bool SetDisplayLevel | ( | int | pEl, | |
| KFbxLodGroup::EDisplayLevel | pValue | |||
| ) |
Set the display level value for the specified object.
- Parameters:
-
pEl The index of the object we want to set the display level. pValue New display level value
- Returns:
- true if successful and false if the specified index is invalid.
| bool GetDisplayLevel | ( | int | pEl, | |
| KFbxLodGroup::EDisplayLevel & | pValue | |||
| ) |
Get the display level value for the specified object.
- Parameters:
-
pEl The index of the object we want to get the display level value. pValue the current display level value.
- Returns:
- true if successfull and false if the specified index is invalid.
- Remarks:
- in case of a failure, the pValue is left unchanged.
Member Data Documentation
| KFbxTypedProperty<fbxBool1> MinMaxDistance |
This property handles the use of the Min/Max distances.
To access this property do: MinMaxDistance.Get(). To set this property do: MinMaxDistance.Set(bool).
Default value is false.
Definition at line 86 of file kfbxlodgroup.h.
| KFbxTypedProperty<fbxDouble1> MinDistance |
This property handles the Min distance value.
To access this property do: MinDistance.Get(). To set this property do: MinDistance.Set(double).
Default value is -100
Definition at line 95 of file kfbxlodgroup.h.
| KFbxTypedProperty<fbxDouble1> MaxDistance |
This property handles the Max distance value.
To access this property do: MaxDistance.Get(). To set this property do: MaxDistance.Set(double).
Default value is 100
Definition at line 104 of file kfbxlodgroup.h.
| KFbxTypedProperty<fbxBool1> WorldSpace |
This property handles the WorldSpace flag.
To access this property do: WorldSpace.Get(). To set this property do: WorldSpace.Set(bool).
Default value is false
Definition at line 113 of file kfbxlodgroup.h.
