Pivot Door

Command entry:

Create panel

(Geometry)

Doors

Pivot button

Command entry:Create menu

AEC Objects

Pivot Door

The Pivot door is hinged on one side only. You can also make the door a double door, with two door elements, each hinged on its outer edge.

Single and double pivot doors

This topic describes only controls and behavior unique to the Pivot door. Most door parameters are common to all kinds of doors; see Doors.

Interface

Parameters rollout

The Parameters rollout contains three check boxes specific to Pivot doors.

Double Doors: Makes a double door.
Flip Swing: Changes the direction the door swings.
Flip Hinge: Places the door hinges on the opposite side of the door. This option is unavailable for double doors.
