Process Tree Controls




Use the following Process Tree controls to manipulate nodes in the schematic.

Show small imageShow large image

(a) Bypass box  (b) Au (Audio) Context button  (c) Selection Mode box

Undo and Redo buttonsUndoes or repeats the last action performed whether in the schematic or in a module. You set the number of undo levels in the Setup menu.

Bypass boxBypasses the selected node according to the option you select. See Bypassing Nodes.

Set Context buttonUses the currently selected node as a context for viewing in a viewport. See Viewing Nodes in Context.

Audio Context buttonUses the currently selected audio clip as a context for another clip. See Working with Audio Contexts.

Update buttonForces an update of nodes that might not have processed the current frame.

Group buttonCreates a group with sets of nodes, branches, or process trees. See Grouping Nodes.

Copy buttonCopies selected items in the schematic. See Copying Nodes.

Delete buttonDeletes selected items in the schematic. See Removing Nodes.

Selection Mode boxDisplays options for the parts of the process tree that you can select. See Selecting Nodes.

Reset buttonResets a node, a branch of nodes, or an entire process tree according to what is selected in the Selection Mode box.

When you reset an Action or a Keyer node, the undo list is cleared. When an Action or a Keyer node is part of a branch in a process tree, you may accidentally clear the undo list when you reset these or other nodes. To prevent the accidental clearing of the undo list when you reset any of these nodes, a warning appears and you are prompted to confirm. For example, when you click Reset to reset a Colour Warper node that is parenting a Keyer node, you must confirm.
