Keyer Node




The Keyer node accepts front, back, and matte clips as input. Before you enter the Keyer module, you can choose to generate a result, matte, or composite clip by selecting the Result, Matte, or Comp view option, respectively, from the Choose Type box before processing.

Show small imageShow large image

(a) Choose Type box  

The Keyer node processes gaps in clips set to No Media based on the input tab receiving the information.

Input Result
Front No media
Back Black frames
Matte Black frames

When working in the Keyer module, missing media in front clips set to No Media are converted into black frames while they are in the editor. When missing media is output from the Keyer node, it returns to a No Media state.

See Keyer.
