#include
<fboptical.h>
Definition at line 310 of file fboptical.h.
Public Member Functions |
|
| FBModelMarkerOptical (char *pName=NULL, HFBModelOptical pOptical=NULL, HIObject pObject=NULL) | |
| Constructor. |
|
| virtual int | ImportBegin () |
| Begin import of optical data. |
|
| virtual bool | ImportKey (double pX, double pY, double pZ=0.0, double pOcclusion=0.0) |
| Import a key of optical data. |
|
| virtual bool | ImportEnd () |
| End importation and clean up data. |
|
| virtual int | ExportBegin () |
| Begin export of optical data. |
|
| virtual bool | ExportKey (double *pX, double *pY, double *pZ=NULL, double *pOcclusion=NULL) |
| Export a key of optical data. |
|
| virtual bool | ExportEnd () |
| End exportation from optical model. |
|
| virtual void | SetModelOptical (HFBModelOptical pOptical) |
| Set the current optical model. |
|
| virtual void | InsertSegmentedData (HFBAnimationNode pTData, HFBAnimationNode pOData) |
| Insert segmented data. |
|
| virtual FBRigidBody | GetRigidBody () |
| Get the rigid body for the marker. |
|
Public Attributes |
|
| FBPropertyModelOptical | Optical |
| Property: Optical model. |
|
| FBPropertyListMarkerSegment | Segments |
| Property: Marker segments. |
|
| FBPropertyListOpticalGap | Gaps |
| Property: Gaps. |
|
| FBPropertyColor | Color |
| Property: Marker color. |
|
| FBPropertyBool | Done |
| Property: Done? |
|
| FBPropertyAnimationNode | Data |
| Property: Data. |
|
| FBModelMarkerOptical | ( | char * | pName = NULL, |
|
| HFBModelOptical | pOptical = NULL, |
|||
| HIObject | pObject = NULL |
|||
| ) |
Constructor.
If no optical model is given, be sure to add one before accessing the Segments and Gaps properties.
| pName | Name of optical marker(default=NULL). | |
| pOptical | Optical model(default=NULL). | |
| pObject | Internal parent object(default=NULL). |
| virtual int ImportBegin | ( | ) | [virtual] |
Begin import of optical data.
Sample communication with optical device and return the number of samples that were taken during the sampling period for statistical purposes.
| virtual bool ImportKey | ( | double | pX, | |
| double | pY, | |||
| double | pZ = 0.0, |
|||
| double | pOcclusion = 0.0 |
|||
| ) | [virtual] |
Import a key of optical data.
| pX | X position. | |
| pY | Y position. | |
| pZ | Z position(default=0.0). | |
| pOcclusion | Occlusion value(default=0.0). |
| virtual bool ImportEnd | ( | ) | [virtual] |
End importation and clean up data.
Interpolates optical data to create a curve from the input key frams.
| virtual int ExportBegin | ( | ) | [virtual] |
Begin export of optical data.
Sample communication with optical device and return the number of samples that were taken during the sampling period for statistical purposes.
| virtual bool ExportKey | ( | double * | pX, | |
| double * | pY, | |||
| double * | pZ = NULL, |
|||
| double * | pOcclusion = NULL |
|||
| ) | [virtual] |
Export a key of optical data.
| pX. | X position. | |
| pY. | Y position. | |
| pZ. | Z position(default=NULL). | |
| pOcclusion. | Occlusion value(default=NULL). |
| virtual bool ExportEnd | ( | ) | [virtual] |
End exportation from optical model.
| virtual void SetModelOptical | ( | HFBModelOptical | pOptical | ) | [virtual] |
Set the current optical model.
| pOptical | New optical model. |
| virtual void InsertSegmentedData | ( | HFBAnimationNode | pTData, | |
| HFBAnimationNode | pOData | |||
| ) | [virtual] |
Insert segmented data.
| pTData | Translation data. | |
| pOData | Occlusion data. |
| virtual FBRigidBody GetRigidBody | ( | ) | [virtual] |
Get the rigid body for the marker.
| FBPropertyModelOptical Optical |
Property: Optical model.
Definition at line 381 of file fboptical.h.
Property: Marker segments.
Definition at line 382 of file fboptical.h.
Property: Gaps.
Definition at line 383 of file fboptical.h.
Property: Marker color.
Reimplemented from FBModelMarker.
Definition at line 384 of file fboptical.h.
Property: Done?
Definition at line 385 of file fboptical.h.
| FBPropertyAnimationNode Data |
Property: Data.
Definition at line 386 of file fboptical.h.
