#include
<fbcontrols.h>
This widget allows users to edit the values of a property without having to manually customize the GUI depending on the type of the property being edited.
SDK objects can have three types of properties:
Another limitation of this widget is that it can only display non hidden internal properties. To get around this issue, the property flag can be changed to unhide it. Doing so will also cause the property to be visible via the property tool.
// In a tool header file...
FBEditProperty mEditProperty;
// In a tool source file...
HFBModel lModel = FBFindModelByName( "ModelName" );
if( lModel )
{
HFBProperty lProperty = lModel->PropertyList.Find( "RotationOrder" );
if( lProperty &&
lProperty->IsInternal() &&
!lProperty->GetPropertyFlag( kFBPropertyFlagHideProperty ))
{
mEditProperty.Property = lProperty;
}
}
Definition at line 2185 of file fbcontrols.h.
Public Member Functions |
|
| FBEditProperty () | |
| Constructor. |
|
Public Attributes |
|
| FBPropertyReference | Property |
| Read Write Property: Property to
edit. Set to NULL to disable. |
|
| FBPropertyDouble | SliderMin |
| Read Write Property: Should the
property be editable using a slider, set the minimum value
atainable with the slider. |
|
| FBPropertyDouble | SliderMax |
| Read Write Property: Should the
property be editable using a slider, set the maximum value
atainable with the slider. |
|
| FBPropertyDouble | SmallInc |
| Read Write Property: Indicate the
small increment applied when click-draging on the property value
(usually right-click-dragging) |
|
| FBPropertyDouble | LargeInc |
| Read Write Property: Indicate the
large increment applied when click-draging on the property value
(usually left-click-dragging) |
|
| FBPropertyDouble | Precision |
| Read Write Property: Used to specify
the width and precision of the value shown. A value of 7.2
indicates to show at minimum 7 numbers, with 2 decimals. |
|
| FBPropertyInt | CaptionSize |
| Read Write Property: Indicate how
much width should the Property Editor reserve for displaying the
property name. |
|
| FBEditProperty | ( | ) |
Constructor.
Read Write Property: Property to edit. Set to NULL to disable.
Definition at line 2191 of file fbcontrols.h.
Read Write Property: Should the property be editable using a slider, set the minimum value atainable with the slider.
Definition at line 2193 of file fbcontrols.h.
Read Write Property: Should the property be editable using a slider, set the maximum value atainable with the slider.
Definition at line 2194 of file fbcontrols.h.
Read Write Property: Indicate the small increment applied when click-draging on the property value (usually right-click-dragging)
Definition at line 2195 of file fbcontrols.h.
Read Write Property: Indicate the large increment applied when click-draging on the property value (usually left-click-dragging)
Definition at line 2196 of file fbcontrols.h.
Read Write Property: Used to specify the width and precision of the value shown. A value of 7.2 indicates to show at minimum 7 numbers, with 2 decimals.
Definition at line 2197 of file fbcontrols.h.
Read Write Property: Indicate how much width should the Property Editor reserve for displaying the property name.
Definition at line 2198 of file fbcontrols.h.
