#include
<fbtracker.h>
This instrument provides the necessary parameters to provide camera tracking support in a device driver (the FBDeviceCamera class and its derivatives). This will also provide a management system for lens look-up tables. Lens tables are used in order to interpret linear encoder values with the non- linear changes in the actual lens.
Definition at line 227 of file fbtracker.h.
Public Member Functions |
|
| FBDeviceCameraInstrument (HFBDevice pDevice) | |
| Constructor. |
|
| virtual bool | LoadLensTables (char *pFilename) |
| Load the lens lookup tables. |
|
| virtual void | ProcessLensData (FBDeviceCameraPacket *pDataPacket) |
| Process the lens table data for this data
packet. |
|
| virtual bool | InstrumentWriteData (HFBEvaluateInfo pEvaluateInfo) override |
| Write data to instrument's connectors.
|
|
| virtual void | InstrumentRecordFrame (FBTime pRecordTime, FBDeviceNotifyInfo &pNotifyInfo) override |
| Record the data to the function curves for
the instrument. |
|
| virtual bool | FbxStore (HFBFbxObject pFbxObject, kFbxObjectStore pStoreWhat) override |
| Storage/Retrieval of information into the
FBX file format. |
|
| virtual bool | FbxRetrieve (HFBFbxObject pFbxObject, kFbxObjectStore pStoreWhat) override |
| Storage/Retrieval of information into the
FBX file format. |
|
Public Attributes |
|
| FBPropertyDeviceCameraPacket | Packet |
| Property(RW): Used as a buffer to
contain the current state of the instrument, use to put data in
connector. |
|
| FBPropertyDeviceCameraPacket | RecordPacket |
| Property(RW): Used as a buffer to
contain the record state of the instrument, use to create the keys
when recording. |
|
| FBPropertyBool | LensTableLoaded |
| Property(R-): Has the lens table been
loaded? |
|
| FBPropertyString | LensCalibrationFilename |
| Property(R-): Lens calibration
filename. |
|
| FBPropertyBool | ManualFovMode |
| Property(RW): In manual mode (not
using encoder values to control zoom)? |
|
| FBPropertyDouble | ManualFovX |
| Property(RW): Manual field of view X
value. |
|
| FBPropertyDouble | ManualFovY |
| Property(RW): Manual field of view Y
value. |
|
| FBPropertyBool | ManualCenterMode |
| Property(RW): Manually adjust the
optical center? |
|
| FBPropertyDouble | ManualCenterX |
| Property(RW): Manual optical center X
coordinate. |
|
| FBPropertyDouble | ManualCenterY |
| Property(RW): Manual optical center Y
coordinate. |
|
| FBPropertyBool | LensFovInDegrees |
| Property(RW): Is FOV in table in
degrees (false) |
|
| FBPropertyBool | InvertZoom |
| Property(RW): Invert the zoom encoder
values? |
|
| FBPropertyBool | InvertFocus |
| Property(RW): Invert the focus
encoder values? |
|
| FBPropertyDouble | ZoomMultiplier |
| Property(RW): Filmback multiplier.
|
|
| FBPropertyDouble | NodalMultiplier |
| Property(RW): Multiplier for nodal
offset. |
|
| FBPropertyVector3d | TranslationOffset |
| Property(RW): Translation offset;
|
|
| FBPropertyVector3d | RotationOffset |
| Property(RW): Rotation offset.
|
|
| FBPropertyDouble | AspectRatio |
| Property(RW): Aspect ratio for
calculating the Field of View X value. |
|
| FBDeviceCameraInstrument | ( | HFBDevice | pDevice | ) |
Constructor.
| pDevice | Parent device. |
| virtual bool LoadLensTables | ( | char * | pFilename | ) | [virtual] |
Load the lens lookup tables.
| pFilename | Name of *.klc file with lens values. |
| virtual void ProcessLensData | ( | FBDeviceCameraPacket * | pDataPacket | ) | [virtual] |
Process the lens table data for this data packet.
The actual operation for this will depend on a couple of properties for the instrument: LensTableLoaded, LensMode, as well as the invert values and the zoom multiplier.
| pDataPacket | Camera data to process with the lens tables. |
| virtual bool InstrumentWriteData | ( | HFBEvaluateInfo | pEvaluateInfo | ) | [override, virtual] |
Write data to instrument's connectors.
In the evaluation engine callback, this will take the data in the instrument's temporary data holders and write it to the connectors.
| pEvaluateInfo | Evaluation information structure. |
Reimplemented from FBDeviceInstrument.
| virtual void InstrumentRecordFrame | ( | FBTime | pRecordTime, | |
| FBDeviceNotifyInfo & | pNotifyInfo | |||
| ) | [override, virtual] |
Record the data to the function curves for the instrument.
| pRecordTime | Time to record data at. | |
| pNotifyInfo | Device notification information structure. |
Reimplemented from FBDeviceInstrument.
| virtual bool FbxStore | ( | HFBFbxObject | pFbxObject, | |
| kFbxObjectStore | pStoreWhat | |||
| ) | [override, virtual] |
Storage/Retrieval of information into the FBX file format.
| pFbxObject | Object to interface with FBX file format. | |
| pStoreWhat | Attributes to store in FBX file. |
Reimplemented from FBDeviceInstrument.
| virtual bool FbxRetrieve | ( | HFBFbxObject | pFbxObject, | |
| kFbxObjectStore | pStoreWhat | |||
| ) | [override, virtual] |
Storage/Retrieval of information into the FBX file format.
| pFbxObject | Object to interface with FBX file format. | |
| pStoreWhat | Attributes to store in FBX file. |
Reimplemented from FBDeviceInstrument.
| FBPropertyDeviceCameraPacket Packet |
Property(RW): Used as a buffer to contain the current state of the instrument, use to put data in connector.
Definition at line 256 of file fbtracker.h.
| FBPropertyDeviceCameraPacket RecordPacket |
Property(RW): Used as a buffer to contain the record state of the instrument, use to create the keys when recording.
Definition at line 257 of file fbtracker.h.
Property(R-): Has the lens table been loaded?
Definition at line 259 of file fbtracker.h.
Property(R-): Lens calibration filename.
Definition at line 260 of file fbtracker.h.
Property(RW): In manual mode (not using encoder values to control zoom)?
Definition at line 262 of file fbtracker.h.
Property(RW): Manual field of view X value.
Definition at line 263 of file fbtracker.h.
Property(RW): Manual field of view Y value.
Definition at line 264 of file fbtracker.h.
Property(RW): Manually adjust the optical center?
Definition at line 265 of file fbtracker.h.
Property(RW): Manual optical center X coordinate.
Definition at line 266 of file fbtracker.h.
Property(RW): Manual optical center Y coordinate.
Definition at line 267 of file fbtracker.h.
Property(RW): Is FOV in table in degrees (false)
Definition at line 268 of file fbtracker.h.
Property(RW): Invert the zoom encoder values?
Definition at line 269 of file fbtracker.h.
Property(RW): Invert the focus encoder values?
Definition at line 270 of file fbtracker.h.
Property(RW): Filmback multiplier.
Definition at line 271 of file fbtracker.h.
Property(RW): Multiplier for nodal offset.
Definition at line 272 of file fbtracker.h.
Property(RW): Translation offset;
Definition at line 273 of file fbtracker.h.
Property(RW): Rotation offset.
Definition at line 274 of file fbtracker.h.
Property(RW): Aspect ratio for calculating the Field of View X value.
Definition at line 275 of file fbtracker.h.
