Changing Playback Scan Mode Options




The options in the Scan Mode box let you view interlaced and progressive material correctly when displayed at a size other than their actual size, for example, when you play an HD clip in the standard-sized Player (in Full Res mode, not Proxies), or a clip proxy in the Source Area, or a clip in Frames view in the Record Area. This option defines the method used to resize the current frame.

To change playback scan mode options:

  1. Click the Player Options tab.
  2. From the Scan option box, select a scan mode for the clip.

    Show small imageShow large image

    Select: To:
    Progressive Resize the frame as a progressive frame. Use this option for progressive material. When applied to interlaced material, field integrity is not retained.
    Field 1 Display only field 1 of an interlaced clip when the clip is stopped. Alternate lines are also filled by field 1. On playback, the interlaced resize method is used.
    Field 2 Display only field 2 of an interlaced clip when the clip is stopped. Alternate lines are also filled by field 2. On playback, the interlaced resize method is used.
    Interlaced Play back the clip with interlaced scan mode. When this option is selected, field 1 and field 2 are resized separately, and then interlaced, producing better results when playing back interlaced material.
