In this area, set the preferences for clip information.
(a) Resolution/Frame Rate Display box (b) Frame ID box (c) Module Frame ID box
Resolution/Frame Rate Display boxUse to show or hide the resolution and frame rate of clips on the desktop reels. The resolution appears in the lower-left corner of each frame. The frame rate appears in the upper-left corner.
| Select: | To display: |
|---|---|
| Resolution and Rate | The clip's frame rate, dimensions, bit depth, aspect ratio, and proxy dimensions. |
| Size and Rate | The clip's frame rate, dimensions, and proxy dimensions. |
| Framerate | The clip's frame rate. |
| Resolution | The clip's dimensions, bit depth, aspect ratio, and proxy dimensions. |
| Size | Clip and proxy dimensions. |
| No Info | No information about resolution or frame rate. |
Frame ID boxUse to select the frame identification mode for all clips on the desktop reels.
| Select: | To display: |
|---|---|
| Src and Rec TC | The source and record timecode. |
| KC and Rec TC | The keycode and record timecode. |
| Keycode | The keycode and frame numbers. |
| Record Timecode | The record timecode and frame numbers. |
| Source Timecode | The source timecode and frame numbers. |
| Frame Numbers | The frame number. |
| No Frame Display | No information about keycode, timecode and frame numbers. |
If the clip has a resolution that does not match the project resolution, the timecode, keycode, or frame numbers that appear on the clip on the desktop and in the clip library are light blue.
The source timecode (on the left) is the timecode on a source clip that you load from a VTR or create in Inferno. The record timecode (on the right) is the timecode on the soft edit.
Module Frame ID boxSelect an option to display the current frame and duration of clips in modules (viewing them in the image window).
