Effects > Colour Warper >

Accessing the Colour Warper

Use the Colour Warper to modify the colour content in your clips. You can manipulate colour content with intuitive controls that provide precise colour correction, and view histograms that help you visualize your image's colours. You can also output a matte corresponding to selected colours.

You can access the Colour Warper as a node that you drag and drop into the Batch process tree. Access the Colour Warper from Batch to modify the colour content of your clips.

You can also access the Colour Warper from the Colour Corrector module. When you access the Colour Warper from the Colour Corrector, they work in parallel—you can colour correct clips with the Colour Corrector and Colour Warper, and then compare the results. Each setup is saved separately.

You should be familiar with using the Batch schematic before using the Colour Warper if you access it from either of these places. See Batch Processing.

To add a Colour Warper node in Batch:

1. In the Main menu, click Processing.
2. In the Processing menu, click Batch, and then select a destination reel.
3. Drag the Colour Warper node from the node bar and add it to the schematic.
4. Input a front clip, a matte clip, or both into the Colour Warper node.
   TipUse a matte clip when you want to colour correct part of the front clip. Only the part of the front clip that is defined by the white part of the matte clip will be affected.
5. If you use both a front and matte clip, make sure they are the same resolution. If they are not, resize them. See Resizing in Batch.
6. Click the Colour Warper node to display the Colour Warper menu.

To access the Colour Warper from the Colour Corrector:

1. Access the Colour Corrector. See Accessing the Colour Corrector.
2. Select CW in the Colour box.




   The Colour Warper menu appears.

   NoteWhen you want to use the Colour Warper in Batch , use the Colour Warper node. You cannot access the Colour Warper through the Colour Corrector when you access it in Batch.

You can access the following menus from the Colour Warper menu.

Basics menuColour correct your clips. You can adjust shadows, midtones, and highlights, and control black and white levels, hue, and saturation. You can also perform colour warping, colour suppression, and colour saturation on a limited range of colour as well as adjust gamma and luminance curves.

Selective menu(part of Basics menu) Define colour ranges using softness and tolerance to create a matte and apply colour correction to a selected region.

Subsetups menuStore, compare, and share Colour Warper subsetups.

Setup menuCustomize your work environment by adjusting vectorscope and hue cube settings, updating colour information, cropping the area you want to colour correct, and inverting a matte.
