Consolidating Clips




Use the Consolidate menu to permanently remove head and tail frames (handles) from a clip—and from the framestore, freeing up space on it. You can keep a number of the existing handles by specifying an upper handles limit before consolidating the clip. For example, if you have a clip with 40 head frames and 10 tail frames, and you consolidate it with a value of 15, the resulting clip has 15 head frames and 10 tail frames.

TipYou can undo a Consolidate command but only prior to entering a module or the Player. For information on undoing commands on the desktop, see Undoing and Redoing Operations.

You may want to consolidate clips with a large number of heads and tails before archiving to avoid archiving unused material.

Use the Consolidate menu to consolidate:

NoteYou can also consolidate clips from the clip library.

Consolidate does not apply to audio.

To remove head and tail frames from a clip:

  1. Click Consolidate in the Editing menu.

    The Consolidate menu appears.

    Show small imageShow large image

    (a) Item Type box  (b) Track box  (c) Handles box  

  2. Select the type of item you want to consolidate from the Item Type box.
  3. Enter the number of handles to keep in the Handles field.
  4. Specify which tracks to consolidate in the Tracks box.
  5. Select the item you are consolidating.
    To select: Click:
    A clip The clip with the red cursor that appears.
    A reel Anywhere on the reel.
    The desktop The Confirm button.
    An element The frame immediately before the element.
    A range The start of the range with the red arrow cursor and the end of the range with the green arrow cursor.
