Introduction

In Maya, rendering refers to the process of creating bitmap images of your scene based on the various shading, lighting, and camera attributes that you set.

When rendering, Maya takes into account all of the various objects and scene attributes, and performs mathematical calculations to produce the final image or image sequence. Once you render a sequence of images, you can then play them back in sequence, producing an animation.

Rendering involves many components to produce an image:

• Shading materials and textures
• Lighting and shadows
• Cameras and animation
• Rendering method
• Visual effects

In Maya, rendering can be accomplished using software (Maya Software Renderer, mental ray^® for Maya^® Renderer, the Maya^® Vector Renderer, or other third party renderer plug-ins) or hardware rendering methods such as the Maya Hardware 2.0 renderer. Each type has its distinct advantages. Which renderer you decide to use will be determined by your image requirements (that is, the look you require) and time constraints.

Software rendering generally allows you to create more precise results but can take longer to produce each frame or image. The Maya software render type uses a process for scene illumination that directly illuminates objects in the scene or simulates illumination by reflecting neighboring objects in the scene or via texture mapping the effect on the object.

The mental ray^® for Maya^® software render type additionally provides a feature called Global Illumination: a process that simulates the effect of indirectly illuminating objects that are not receiving direct illumination. It can also simulate light effects known as caustics.

Hardware rendering is generally faster but is less capable of producing detailed results. You can use the Maya Hardware 2.0 renderer to render in the scene view or to batch render. The Hardware 2.0 renderer provides large scene performance optimization and higher quality lighting and shaders.

Some visual effects can only be produced via one method; at times, a combination of more than one type of rendering method may be required.

Rendering usually requires several iterations to achieve the final image that meets your requirements. The key is to strike the balance between producing the image that meets your requirements and producing it in the time required. This is particularly important if you are using Maya in a production setting.

This chapter introduces you to some of the fundamental concepts and skills related to rendering. This chapter includes the following lessons:

• Lesson 1 Rendering a scene: Introduction
• Lesson 2 Shading surfaces: Introduction
• Lesson 3 Lights, shadows, and cameras: Introduction
• Lesson 4 Global Illumination: Introduction
• Lesson 5 Caustics: Introduction
