MFnPointOnSurfaceManip Class Reference
[OpenMayaUI - API module for user interface, FunctionSet classes]

#include <MFnPointOnSurfaceManip.h>

Inheritance diagram for MFnPointOnSurfaceManip:

[legend]

Collaboration diagram for MFnPointOnSurfaceManip:

[legend]

List of all members.

---

Detailed Description

PointOnSurfaceManip function set.

The PointOnSurfaceManip allows the user to manipulate a point constrained to move along a surface, in order to specify the (u, v) surface parameter values. This manipulator generates two floating point values corresponding to the surface (u, v) parameters.

Examples:

surfaceBumpManip.cpp.

Public Member Functions
virtual MFn::Type	type () const
	Function set type.
virtual	~MFnPointOnSurfaceManip ()
	Destructor.
	MFnPointOnSurfaceManip ()
	Default constructor.
	MFnPointOnSurfaceManip (MObject &object, MStatus *ReturnStatus=NULL)
	Constructor.
	MFnPointOnSurfaceManip (const MDagPath &object, MStatus *ret=NULL)
	Constructor.
MObject	create (MStatus *ReturnStatus=NULL)
MObject	create (const MString &manipName, const MString &paramName, MStatus *ReturnStatus=NULL)
MStatus	connectToSurfacePlug (MPlug &surfacePlug)
MStatus	connectToParamPlug (MPlug &paramPlug)
MStatus	setDrawSurface (bool state)
MStatus	setDrawArrows (bool state)
MStatus	setParameters (double u, double v)
MStatus	getParameters (double &u, double &v)
bool	isDrawSurfaceOn (MStatus *ReturnStatus=NULL) const
unsigned int	surfaceIndex (MStatus *ReturnStatus=NULL) const
unsigned int	paramIndex (MStatus *ReturnStatus=NULL) const
	MFnPointOnSurfaceManip (const MObject &object, MStatus *ret=NULL)
	Constructor.
Protected Member Functions
virtual const char *	className () const
	Class name.

---

Constructor & Destructor Documentation

MFnPointOnSurfaceManip::~MFnPointOnSurfaceManip

(

)

[virtual]

Destructor.

Class destructor.

MFnPointOnSurfaceManip::MFnPointOnSurfaceManip	(	MObject &	object,
		MStatus *	ReturnStatus = NULL
	)

Constructor.

Class constructor that initializes the function set to the given MObject.

Parameters:

[in]	object	The MObject to attach the function set to
[out]	ReturnStatus	the return status

Status Codes:

• MS::kSuccess if the function set is successfully attached
• MS::kInvalidParameter if the MObject does not represent a valid Maya object or if the function set is not allowed to attach to this MObject

MFnPointOnSurfaceManip::MFnPointOnSurfaceManip	(	const MDagPath &	object,
		MStatus *	ReturnStatus = NULL
	)

Constructor.

Class constructor that initializes the function set to the given constant MDagPath object.

Parameters:

[in]	object	The const MDagPath to attach the function set to
[out]	ReturnStatus	The return status

Status Codes:

• MS::kSuccess if the function set is successfully attached
• MS::kInvalidParameter if the MObject does not represent a valid Maya object or if the function set is not allowed to attach to this MObject

MFnPointOnSurfaceManip::MFnPointOnSurfaceManip	(	const MObject &	object,
		MStatus *	ReturnStatus = NULL
	)

Constructor.

Class constructor that initializes the function set to the given MObject.

Parameters:

[in]	object	The MObject to attach the function set to
[out]	ReturnStatus	the return status

Status Codes:

• MS::kSuccess if the function set is successfully attached
• MS::kInvalidParameter if the MObject does not represent a valid Maya object or if the function set is not allowed to attach to this MObject

---

Member Function Documentation

MFn::Type MFnPointOnSurfaceManip::type

(

)

const [virtual]

Function set type.

Return the class type : MFn::kPointOnSurfaceManip

Reimplemented from MFnManip3D.

const char * MFnPointOnSurfaceManip::className

(

)

const [protected, virtual]

Class name.

Return the class name : "MFnPointOnSurfaceManip"

Reimplemented from MFnManip3D.

MObject MFnPointOnSurfaceManip::create

(

MStatus *

ReturnStatus = NULL

)

Creates a new PointOnSurfaceManip. This function set's object is set to be the new manipulator.

This method should only be used to create a non-composite PointOnSurfaceManip.

The name that appears in the feedback line is "param"

Parameters:

[out]

ReturnStatus

return status

Returns:

Newly created PointOnSurfaceManip

Status Codes:

• MS::kSuccess operation successful
• MS::kFailure operation failed

MObject MFnPointOnSurfaceManip::create	(	const MString &	manipName,
		const MString &	paramName,
		MStatus *	ReturnStatus = NULL
	)

Creates a new PointOnSurfaceManip. This function set's object is set to be the new manipulator.

This method should only be used to create a non-composite PointOnSurfaceManip.

The name that appears in the feedback line is specified by the paramName argument.

Parameters:

[in]	paramName	the name that appears in the feedback line
[out]	ReturnStatus	return status

Returns:

Newly created PointOnSurfaceManip

Status Codes:

• MS::kSuccess operation successful
• MS::kFailure operation failed

Reimplemented from MFnDependencyNode.

MStatus MFnPointOnSurfaceManip::connectToSurfacePlug

(

MPlug &

surfacePlug

)

Connect to the surface plug. The data type corresponding to the surfacePlug is MFnData::kNurbsSurface.

Parameters:

[in]

surfacePlug

the surface plug

Returns:

• MS::kSuccess operation successful
• MS::kFailure operation failed

MStatus MFnPointOnSurfaceManip::connectToParamPlug

(

MPlug &

paramPlug

)

Connect to the param plug. The data type corresponding to the paramPlug is MFnNumericData::k2Double.

Parameters:

[in]

paramPlug

the param plug

Returns:

• MS::kSuccess operation successful
• MS::kFailure operation failed

MStatus MFnPointOnSurfaceManip::setDrawSurface

(

bool

state

)

Sets whether or not the surface is drawn.

Parameters:

[in]

state

whether or not the surface should be drawn

Returns:

• MS::kSuccess operation successful
• MS::kFailure operation failed

MStatus MFnPointOnSurfaceManip::setDrawArrows

(

bool

state

)

Sets whether or not the arrows should be drawn.

Parameters:

[in]

state

whether or not the arrows should be drawn

Returns:

• MS::kSuccess operation successful
• MS::kFailure operation failed

MStatus MFnPointOnSurfaceManip::setParameters	(	double	u,
		double	v
	)

Sets the u and v parameters.

Parameters:

[in]	u	u parameter
[in]	v	v parameter

Returns:

• MS::kSuccess operation successful
• MS::kFailure operation failed

MStatus MFnPointOnSurfaceManip::getParameters	(	double &	u,
		double &	v
	)

Returns the parameter.

Parameters:

[out]	u	u parameter
[out]	v	v parameter

Returns:

• MS::kSuccess operation successful
• MS::kFailure operation failed

bool MFnPointOnSurfaceManip::isDrawSurfaceOn

(

MStatus *

ReturnStatus = NULL

)

const

Returns whether or not the surface is drawn.

Parameters:

[out]

ReturnStatus

return status

Returns:

• true the surface is being drawn
• false the surface is not being drawn

Status Codes:

• MS::kSuccess operation successful
• MS::kFailure operation failed

unsigned int MFnPointOnSurfaceManip::surfaceIndex

(

MStatus *

ReturnStatus = NULL

)

const

Returns the index of the surface. The data type corresponding to this index is MFnData::kNurbsSurface.

Parameters:

[out]

ReturnStatus

return status

Returns:

Surface index

Status Codes:

• MS::kSuccess operation successful
• MS::kFailure operation failed

unsigned int MFnPointOnSurfaceManip::paramIndex

(

MStatus *

ReturnStatus = NULL

)

const

Returns the index of the parameter of the PointOnSurfaceManip. The data type corresponding to this index is MFnNumericData::k2Double.

Parameters:

[out]

ReturnStatus

return status

Returns:

Parameter index

Status Codes:

• MS::kSuccess operation successful
• MS::kFailure operation failed
