#include
<MFnSpotLight.h>
List of all
members.
Detailed Description
Manage Spot Light dependency Nodes.
MFnSpotLight facilitates
creation and manipulation of dependency graph nodes representing
spotlights.
|
Public Types
|
enum |
MBarnDoor
{
kLeft,
kRight,
kTop,
kBottom } |
|
Available doors for barnDoor-related
methods. More...
|
enum |
MDecayRegion
{
kFirst,
kSecond,
kThird } |
|
Decay regions. More...
|
Public Member Functions
|
virtual MFn::Type |
type
() const |
|
Function set type.
|
virtual |
~MFnSpotLight
() |
|
Destructor.
|
|
MFnSpotLight
() |
|
Default constructor.
|
|
MFnSpotLight
(MObject &object,
MStatus
*ReturnStatus=NULL) |
|
Constructor.
|
|
MFnSpotLight
(const MDagPath
&object, MStatus
*ret=NULL) |
|
Constructor.
|
MObject |
create
(bool UIvisible=true, MStatus *ReturnStatus=NULL) |
MObject |
create
(const MObject
&parent, bool UIvisible=true, bool wantTransform=false,
MStatus
*ReturnStatus=NULL) |
double |
coneAngle
(MStatus
*ReturnStatus=NULL) const |
MStatus |
setConeAngle
(const double &coneAngle) |
double |
penumbraAngle
(MStatus
*ReturnStatus=NULL) const |
MStatus |
setPenumbraAngle
(const double &penumbraAngle) |
double |
dropOff
(MStatus
*ReturnStatus=NULL) const |
MStatus |
setDropOff
(const double &dropOff) |
bool |
barnDoors
(MStatus
*ReturnStatus=NULL) const |
MStatus |
setBarnDoors
(const bool &barnDoors) |
double |
barnDoorAngle
(MBarnDoor
which_door, MStatus
*ReturnStatus=NULL) const |
MStatus |
setBarnDoorAngle
(MBarnDoor
which_door, const double &barn_door_angle) |
bool |
useDecayRegions
(MStatus
*ReturnStatus=NULL) const |
MStatus |
setUseDecayRegions
(const bool &use_decay_regions) |
float |
startDistance
(MDecayRegion
which_region, MStatus
*ReturnStatus=NULL) const |
MStatus |
setStartDistance
(MDecayRegion
which_region, const float &start_distance) |
float |
endDistance
(MDecayRegion
which_region, MStatus
*ReturnStatus=NULL) const |
MStatus |
setEndDistance
(MDecayRegion
which_region, const float &end_distance) |
|
MFnSpotLight
(const MObject
&object, MStatus
*ret=NULL) |
|
Constructor.
|
MObject |
create
(const MObject
&parent, bool UIvisible=true, MStatus *ReturnStatus=NULL) |
|
NO SCRIPT SUPPORT.
|
Protected Member Functions
|
virtual const char * |
className
() const |
|
Class name.
|
Member Enumeration Documentation
Available doors for barnDoor-related methods.
- Enumerator:
-
kLeft |
|
kRight |
|
kTop |
|
kBottom |
|
Decay regions.
- Enumerator:
-
Constructor & Destructor Documentation
MFnSpotLight::~MFnSpotLight |
( |
|
) |
[virtual] |
Destructor.
The class destructor.
MFnSpotLight::MFnSpotLight |
( |
MObject & |
object, |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
|
Constructor.
Class constructor that initializes the function set to the given
MObject.
- Parameters:
-
[in] |
object |
The MObject to
attach the function set to |
[out] |
ReturnStatus |
the return status |
- Status Codes:
-
MFnSpotLight::MFnSpotLight |
( |
const MDagPath & |
object, |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
|
Constructor.
Class constructor that initializes the function set to the given
constant MDagPath object.
- Parameters:
-
[in] |
object |
The const MDagPath to attach the function set to |
[out] |
ReturnStatus |
The return status |
- Status Codes:
-
MFnSpotLight::MFnSpotLight |
( |
const MObject & |
object, |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
|
Constructor.
Class constructor that initializes the function set to the given
MObject.
- Parameters:
-
[in] |
object |
The MObject to
attach the function set to |
[out] |
ReturnStatus |
the return status |
- Status Codes:
-
Member Function Documentation
MFn::Type
MFnSpotLight::type |
( |
|
) |
const [virtual] |
const char * MFnSpotLight::className |
( |
|
) |
const [protected, virtual] |
MObject MFnSpotLight::create |
( |
bool |
UIvisible = true , |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
|
Creates a new spotlight dependency graph node and adds it to the
dependency graph. If the UIvisible parameter is true, the new node
will be connected to the light classification node (which allows
the UI to recognize the node as a light) and added to the default
light list. If UIvisible is false, the node will be created in
isolation.
The light node is added to the current model, under a new
transformation.
- Parameters:
-
[in] |
UIvisible |
determines whether or not to connect the new node to the light
classification node and add it to the default light list. |
[out] |
ReturnStatus |
return status |
- Returns:
- MObject
representing the new dependency node.
- Status Codes:
-
MObject MFnSpotLight::create |
( |
const MObject & |
parent, |
|
|
bool |
UIvisible = true , |
|
|
bool |
wantTransform =
false , |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
|
Creates a new spotlight dependency graph node and adds it to the
dependency graph. If the UIvisible parameter is true, the new node
will be connected to the light classification node (which allows
the UI to recognize the node as a light) and added to the default
light list. If UIvisible is false, the node will be created in
isolation.
If wantTransform parameter is false ( which is by default ), the
new shape node is created under the specified parent and no
transform node is created. If the specified parent is null, then no
shape node will be created.
The light node is added to the current model, under the
specified parent.
- Parameters:
-
[in] |
parent |
the node under which the new light and its transform will be
added. |
[in] |
wantTransform |
Boolean to indicate whether the transform node is needed or
not, which is 'false' by default. |
[in] |
UIvisible |
determines whether or not to connect the new node to the light
classification node and add it to the default light list. |
[out] |
ReturnStatus |
return status |
- Returns:
- MObject
representing the new dependency node.
- Status Codes:
-
double MFnSpotLight::coneAngle |
( |
MStatus * |
ReturnStatus =
NULL |
) |
const |
Retrieves the value of the "coneAngle" attribute of a light
node. This attribute represents the angle that the spotlight cone
makes with the spotlight direction vector.
- Parameters:
-
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the "coneAngle" attribute of the light node.
- Status Codes:
-
MStatus MFnSpotLight::setConeAngle |
( |
const double & |
cone_angle |
) |
|
Sets the value of the "coneAngle" attribute of a light node.
- Parameters:
-
[in] |
cone_angle |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
double MFnSpotLight::penumbraAngle |
( |
MStatus * |
ReturnStatus =
NULL |
) |
const |
Retrieves the value of the "penumbraAngle" attribute of a light
node. This attribute represents the extra angle beyond the cone
angle used in soft shadow computations.
- Parameters:
-
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the "penumbraAngle" attribute of the light
node.
- Status Codes:
-
MStatus
MFnSpotLight::setPenumbraAngle |
( |
const double & |
penumbra_angle |
) |
|
Sets the value of the "penumbraAngle" attribute of a light
node.
- Parameters:
-
[in] |
penumbra_angle |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
double MFnSpotLight::dropOff |
( |
MStatus * |
ReturnStatus =
NULL |
) |
const |
Retrieves the value of the "dropOff" attribute of a light node.
This attribute represents the degree to which intensity of the
light decreases with increasing angular distance from the light
direction vector. Higher values represent more rapid intensity
dropoff.
- Parameters:
-
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the "dropOff" attribute of the light node.
- Status Codes:
-
MStatus MFnSpotLight::setDropOff |
( |
const double & |
drop_off |
) |
|
Sets the value of the "dropOff" attribute of a light node.
- Parameters:
-
[in] |
drop_off |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
bool MFnSpotLight::barnDoors |
( |
MStatus * |
ReturnStatus =
NULL |
) |
const |
Retrieves the value of the "barnDoors" attribute of a light
node. This attribute determines whether or not the light uses barn
doors.
- Parameters:
-
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the "barnDoors" attribute of the light node.
- Status Codes:
-
MStatus MFnSpotLight::setBarnDoors |
( |
const bool & |
barn_doors |
) |
|
Sets the value of the "barnDoors" attribute of a light node.
- Parameters:
-
[in] |
barn_doors |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
double MFnSpotLight::barnDoorAngle |
( |
MBarnDoor |
which_door, |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
const |
Retrieves the value of the barn door angle for the specified
barn door. The barn door angles are represented by the
"leftBarnDoor", "rightBarnDoor", "topBarnDoor", and
"bottomBarnDoor" attributes. This function retrieves the value of
the appropriate attribute.
- Parameters:
-
[in] |
which_door |
which barn door to return. |
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the appropriate barn door angle attribute of the
light node.
- Status Codes:
-
- MS::kSuccess
operation successful
- MS::kFailure function set
does not have a valid object, or the specified barn door was
invalid.
MStatus
MFnSpotLight::setBarnDoorAngle |
( |
MBarnDoor |
which_door, |
|
|
const double & |
barn_door_angle |
|
|
) |
|
|
|
Sets the value of the appropriate barn door angle attribute of a
light node.
- Parameters:
-
[in] |
which_door |
Which barn door to return. |
[in] |
barn_door_angle |
New value for the barn door. |
- Returns:
- Return status
- Status Codes:
-
- MS::kSuccess
operation successful
- MS::kFailure function set
does not have a valid object, or the specified barn door was
invalid.
bool MFnSpotLight::useDecayRegions |
( |
MStatus * |
ReturnStatus =
NULL |
) |
const |
Retrieves the value of the "useDecayRegions" attribute of a
light node. This attribute determines whether or not the light uses
decay regions.
- Parameters:
-
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the "useDecayRegions" attribute of the light
node.
- Status Codes:
-
MStatus
MFnSpotLight::setUseDecayRegions |
( |
const bool & |
use_decay_regions |
) |
|
Sets the value of the "useDecayRegions" attribute of a light
node.
- Parameters:
-
[in] |
use_decay_regions |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
float MFnSpotLight::startDistance |
( |
MDecayRegion |
which_region, |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
const |
Retrieves the value of the start distance for the specified
decay regions. The start distances for the spotlight's 3 decay
regions are represented by the "startDistance1", "startDistance2",
and "startDistance3" attributes. This function retrieves the value
of the appropriate attribute.
- Parameters:
-
[in] |
which_region |
the decay region whose startDistance attribute is to be
retrieved. |
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the appropriate startDistance attribute of the
light node.
- Status Codes:
-
- MS::kSuccess
operation successful
- MS::kFailure function set
doesn not have a valid object, or the specified decay region was
invalid.
MStatus
MFnSpotLight::setStartDistance |
( |
MDecayRegion |
which_region, |
|
|
const float & |
start_distance |
|
|
) |
|
|
|
Sets the value of the appropriate decay region start distance
attribute of a light node.
- Parameters:
-
[in] |
which_region |
the decay region whose start distance is to be set. |
[in] |
start_distance |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
- MS::kSuccess
operation successful
- MS::kFailure function set
does not have a valid object, or the specified decay region was
invalid.
float MFnSpotLight::endDistance |
( |
MDecayRegion |
which_region, |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
const |
Retrieves the value of the end distance for the specified decay
regions. The end distances for the spotlight's 3 decay regions are
represented by the "endDistance1", "endDistance2", and
"endDistance3" attributes. This function retrieves the value of the
appropriate attribute.
- Parameters:
-
[in] |
which_region |
the decay region whose endDistance attribute is to be
retrieved. |
[out] |
ReturnStatus |
return status |
- Returns:
- The value of the appropriate endDistance attribute of the light
node.
- Status Codes:
-
- MS::kSuccess
operation successful
- MS::kFailure function set
doesn not have a valid object, or the specified decay region was
invalid.
Sets the value of the appropriate decay region end distance
attribute of a light node.
- Parameters:
-
[in] |
which_region |
the decay region whose end distance is to be set. |
[in] |
end_distance |
value to which the attribute will be set. |
- Returns:
- Return status
- Status Codes:
-
- MS::kSuccess
operation successful
- MS::kFailure function set
does not have a valid object, or the specified decay region was
invalid.
MObject MFnSpotLight::create |
( |
const MObject & |
parent, |
|
|
bool |
UIvisible = true , |
|
|
MStatus * |
ReturnStatus =
NULL |
|
|
) |
|
|
|
NO SCRIPT SUPPORT.
Creates a new spotlight dependency graph node and adds it to the
dependency graph. If the UIvisible parameter is true, the new node
will be connected to the light classification node (which allows
the UI to recognize the node as a light) and added to the default
light list. If UIvisible is false, the node will be created in
isolation.
The light node is added to the current model, under a new
transformation. The transformation is added to the current model
under the specified parent.
- Parameters:
-
[in] |
parent |
the node under which the new light and its transform will be
added. |
[in] |
UIvisible |
determines whether or not to connect the new node to the light
classification node and add it to the default light list. |
[out] |
ReturnStatus |
return status |
- Returns:
- MObject
representing the new dependency node.
- Status Codes:
-
