Create a fillet between two surfaces

Create a circular fillet

1. Select two intersecting surfaces.
2. Select Edit NURBS > Surface Fillet > Circular Fillet > .
3. Do any of the following:
   • Use the channel box, attribute editor, or Show Manipulator tool to change the radii.
   • Select one of the surfaces and choose Edit NURBS > Reverse Surface Direction to change which side of the surface the fillet is built on.

Create a freeform fillet

1. Select an isoparm or curve-on-surface on each surface as the start and end points of the fillet.
2. Select Edit NURBS > Surface Fillet > Freeform Fillet.



3. Do any of the following:
   • Use the channel box, attribute editor, or Show Manipulator tool to edit the fillet.
   • To manipulate the isoparms used to create the fillet, select the one of the curveFromSurface nodes.
