Master Track Key Info Dialog (Master Point Controller)



Command entry:Track View - Dope Sheet Right-click a master track key in the Dope Sheet Key window. Master Track Key Info dialog

With Track View in Dope Sheet mode, right-click a green master key of a Master Point controller to open the Master Track Key Info dialog.

Interface

[key arrows]

Moves to the next or previous key.

Time

Moves the master key to a different frame or time.

Sub Keys list window

Displays all the animated sub-object keys at a particular frame or time.

Select Point

Select a node in the List Window and the corresponding node in the viewports is selected, if the corresponding sub-object level is active.

Key Frame Properties

Displays and lets you adjust interpolation and position. See Bezier Controller.
